Found 2 results

  1. One of last year's find at the Covered Bridge Festival yielded one of my prized push drills now that I have it operational. A Millers-Falls, Model 100 (aka Buck Rogers). Found it in a pile of stuff but no price. I finally found the vendor and asked how much for this...He replied "I don't even know what that is...how about $3.75?" I couldn't get my money clip out fast enough...I didn't know how many bits were trapped inside, but it had an original tube which contained several I could tell. Mom's illness came shortly thereafter, then all the trips & time to the hospital, the nursing home, then eventually her passing, many things were placed on the back burner for some time. A few weeks ago, I decided it was time to figure this thing out so here's the journey. Thanks for looking... As purchased...you can see the Red Tenite has the typical "mold" from age, and exposure. It really stinks too. Bits in the tube turned out to be straight shank probably for an egg-beater style. Not for this drill or any of the Stanley style either. After some internet searches, I finally found some information on how to disassemble the 100. Soaking with WD-40 still would not free up the Red handle portion to rotate easily to remove the bits in the handle. The multiple layers of blue masking tape provided a gripping area where I could use gripping pliers without damaging the aluminum. I had tried strap wrenches with no success. Even at this stage, I still could not get the handle to rotate easily or to further clean. NOTE: The wood plunger. This one appeared to be turned from maple. You can also see the "gang green" transferred from the brass. I had pre-cleaned the Tenite handle first using a nylon scraper, then green Scotch-Brite. Cleaned the plunger with Acetone, Scotch-Brite, then 3 or 4 coats of Johnson's Wax. I added another layer of painters tape to the plunger barrel to remove it from the spiral drive. Handle was cleaned with Simple Green & water mix then buffed on the lose sewn buffing wheel and Blue Compound specific for plastic...yep it still stinks. The adapter on the right by the plunger barrel incurred some damage to the internal spirals as well as the shoulder during removal. I had to use an Easy-Out.; spent a lot of time with jewelers files to repair, but getting it out let me finally get the handle free. I chose not to to remove the brass tube from the end cap fearing I would collapse it trying to get a firm grip. A lot of cleaning and polishing with the Dremel, hand polishing with 240-400 grill wet/dry and also final buffing with different compounds at the buffer. I made a flap sander from a 1/4" bolt shank by cutting a slot in the shaft to wrap sand paper arse a way to flap and enlarge the ID of the handle some. I guess the Tenite either shrinks (it certainly stinks) over time or maybe the WD-40 had an adverse effect on it. Anyway, after ever thing was cleaned and polished, it still would not rotate freely on the brass sleeve without flapping. Sub-assembled with white grease to lube all the internal moving parts; The reveal after tape removed and everything cleaned and polished. Oh yeah, it was worth the patience & work as all 8 original bits with minimal surface rust were in the handle turret I don't think this had been used much and some bits not at all. All bits were buffed with the Dremel and scrubbed with Johnson's and a toothbrush. The non-matching bits will get a new assignment to one of my egg-beater drills. Ready for it's new luxury dwelling. Thanks for looking.
  2. Technically, it's still not a collection since there are <24, but I may have OCTD (Obsessive Compulsive Tool Disorder). This habit began in 1972 although I didn't know it at the time. My dad had a Yankee, Model 46 push drill so it just made sense to get one of my own. There were no BORGs back then; I bought mine from one of the old fashioned hardware stores which was down-town...same place you bought nails, screws, tools, grass & vegetable seeds, paint,,,well you get it...they were a Blue Grass / Belknap franchise, but sold other brands as well. I had just purchased my first "home" so to speak...a 1959, 10'x50', 3 'bedroom' mobile home on a little over 1/2 acre lot. Fast forward about 37 years...my daughter rented her first house...needed curtain rods put up...got my old Model 46 out as I had tens of dozens time before for just this kind of task...she said, "dad I'd really like one of those." No problem, I'll just look it up on-line and order one...apparently Stanley quit making these sometime in the early 1980's...who knew...the quest began...at the time similar were selling for $25-$100 on eBay plus shipping...started looking at yard sales & flea markets...took a few months but I found a like new 41Y Bell Systems with all 8 bits for $5...she got it for Christmas that year. But the obsession grew...what if I broke a bit on mine? What if I lost it after all these years...so the pictures below reflect the rest...anyways, that's my story and I'm sticking to it. Top Row L->R 46Y, no cap/bits perfect otherwise; 46; some bits, works well, cap and handle nasty; my original 46 still have original 8 bits; red handle/black cap also a 46, but marked Yankee North Bros (note in right side pic has the original instructions which are rolled up and placed in one of the bits slots; has 7/8 of bits missing 1/16"; black bakelite handle, chrome steel cap, 45, Yankee, some bits but a couple are Stanley slot shank but twist bits, Made In Germany so likely Dunlap; far right Stanley 03-049; cheaper version of the Yankee's; probably made toward the end of the production; bottom of all in top two pics, is a new replacement driver shank tht would work on all 46 models. Bottom left, one on left is marked Made in Germany, but on the cap embossed Dunlap; second red cap only marked Made in Germany...may be an earlier version of one on the left. Right pic, Blue capped is one of my prize treasures...no bits, marked Made in Germany and is very similar to the Dunlap's but with one major difference.There is an inverted triangle; above the triangle is "Manufacturers Steel Corp"; left side of the triangle marked "Germany"; right side of the triangle "British Zone"; from what I have been able to learn, this would have been produced somewhere between 1945-1954; Allied's occupation of Germany ceased after 1954...likely this was made after 1946 since Germany was allowed little production of any kind until about 1948 and before 1953 as Allied's lessened controls after that. I believe it to be the the first runs of what became Dunlap. I gave 25 cents for it. Sorry for glare but maybe you can see Dunlap on cap; far right are the latest picks; (2)-Stanley 41Y's and the Miller-Falls #100 $2-$3-$2 Left picture, top to bottom; Yankee North Bros No 40? can't make out '0" but believe it to be one of the first in the series; Next is Steel Craft-Germany-may be part of the same era of Occupied Germany; it's a Stanley 41 clone; Yankee North Bros, #41; a nice Yankee North Bros 41 but slightly different chuck than one above; a very nice Yankee North Bros 41 but again another variation of chuck than one above; Yankee North Bros, #44; note the bits store different on this one. A grand total of 17-3/4 (18-3/4 if you count my daughters, but it's not on location so...) Outside of hers at $5 and whatever mine might have cost new, I've never given or $2-3 for any of the rest...most a buck or less. I've let at least this many go just because they were priced above $5... So if you've read this far without your head slamming the table, keyboard or screen, thanks for indulging my OCTD.
×
×
