- 30 replies
Got the CNC working today. I am cutting dadoes and shelf pin holes for the ten cabinet sides that I am building. These are the wall cabinets 39 inches tall. I have to flip the pieces once end for end because I don't have the cutting capacity to do it in one pass. If they were 37 inches, or shorter, that would be perfect. I could lay them on the x axis and make the cuts in one pass.
So, I start the cut, then go inside the house (only a few steps away), and watch a little drag racing or other things on the computer. When I hear the router shut down, I go out and flip the piece and run the file again. The sides are identical with the dadoes cut 2 inches from each end. Then half of the shelf pins are drilled starting 8 inches above where the shelf bottom (or top) will be. So I end up with identical pieces that can actually be flipped if needed, but I won't do that. I have the top of each piece marked.
Note: The work pieces are already cut to final width and length, and clamped to the bed of the CNC with the long end on the Y axis. My file cuts the dado and half of the shelf pins (1 1/4 inches apart). After flipping the work piece and cutting the remaining half, I have one side that is complete.
OOPS!, I just heard it shut down. Gotta go. Only two more sides left and I will be through. Tough job, but somebody's got to do it!
- 31 replies
Dang, hate it when that happens. Have done a few successful forms the last couple of weeks and I guess I just got to aggressive on this one. Didn't have any idea I was in trouble until it separated. I was really pleased with the form on this one too. Oh well, it's how we learn!! Movin' on
- 8 replies
I had seen a Woodsmith video where they demonstrated how to trim the edge with a router, so I tried it. That was easy and went fairly quick also.
Basically, you do two or more shelves at a time. Put them on edge with a spacer in between. Then run a router with a flush trim bit along the edges. Zoom, zoom! I think the pictures tell the story better than I can describe it. The wooden hand clamps worked very well to stabilize the whole thing. Well, I might have used a couple more clamps to keep everything stable.
- 8 replies
